130 Upgrade and Maintenance Manual
TX140 S2
Hard disk drives / solid state drives
7.2.5.2 Removing a 2.5-inch HDD / SSD module
Ê Remove the HDD / SSD module to be replaced from the server as described
in section "Removing a 2.5-inch HDD / SSD module" on page 127.
7.2.5.3 Installing a 2.5-inch HDD / SSD module
Ê Install the new HDD / SSD module into the empty drive bay as described in
section "Installing 2.5-inch HDD / SSD modules" on page 124.
7.2.5.4 Concluding steps
Ê If applicable, "Installing the HDD bay cover" on page 64
Ê "Performing a RAID array rebuild" on page 91
7.2.6 Replacing a 2.5-inch HDD SAS / SATA backplane
7.2.6.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Disabling BitLocker functionality" on page 69
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê If applicable, "Removing the HDD bay cover" on page 55
Ê "Removing 2.5-inch HDD / SSD modules" on page 126
V CAUTION!
Ensure that all hard disk drives are uniquely identified so that you can
reinsert them into their original bays after replacing the SAS / SATA
backplane.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
