TX140 S2
Upgrade and Maintenance Manual 195
Expansion cards and backup units
9.5.2.5 Connecting the FBU adapter cable to the TFM
Figure 114: Routing the FBU adapter cable
Ê Connect the FBU adapter cable to the TFM.
Ê Route the FBU adapter cable as shown.
9.5.2.6 Concluding steps
Ê "Installing the fan module" on page 152
Ê "Reassembling" on page 58
Ê "Connecting the server to the mains" on page 67
Ê "Switching on the server" on page 68
Ê "Updating RAID controller firmware" on page 80
Ê "Enabling SVOM boot watchdog functionality" on page 85
