218 Upgrade and Maintenance Manual
TX140 S2
Processors
11.1 Basic information
Supported processors
The system board is equipped with one LGA 1150 socket for dual and quad
Core Intel Xeon E3-1200v3 processor series CPUs.
11.2 Upgrading or replacing the processor
V CAUTION!
Processors are extremely sensitive to electrostatic discharge and must
be handled with care. After a processor has been removed from its
protective sleeve or from its socket, place it upside down on a
nonconducting, antistatic surface. Never push a processor over a
surface.
11.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 69
Ê "Disabling SVOM boot watchdog functionality" on page 70
Ê If applicable, "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Removing the fan module" on page 151
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
