308 Upgrade and Maintenance Manual
TX140 S2
Cabling
16.3 Replacing the intrusion switch cable
16.3.1 Preliminary steps
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
Ê "Removing the rack front cover" on page 52 (rack server) or "Removing the
front cover" on page 56 (tower server)
16.3.2 Removing the defective intrusion switch cable
Figure 210: Disconnecting the intrusion switch cable
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
