Fujitsu PRIMERGY TX140 S2 - USB Flash Module (UFM); Installing the UFM; Preliminary Steps

TX140 S2 Upgrade and Maintenance Manual 255
System board and components
14.3 USB Flash Module (UFM)
14.3.1 Installing the UFM
14.3.1.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 69
Ê "Disabling SVOM boot watchdog functionality" on page 70
Ê "Locating the defective server" on page 43
Ê "Shutting down the server" on page 46
Ê "Disconnecting the server from the mains" on page 46
Ê "Getting access to the component" on page 47
14.3.1.2 Installing the UFM
Figure 160: UFM kit
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Software: 5 minutes
Tools: tool-less
1 USB Flash Module (UFM) 2 UFM spacer
3 UFM nylon screw
