300 Upgrade and Maintenance Manual
TX140 S2
Cabling
16.1 List of used cables
I The numbers in the cable list correspond to those shown in the cabling
plans.
No. Name Cable number Routing
1 Front panel cable T26139-Y4015-V301
from front panel module to system
board
2 Front USB cable T26130-Y3999-V301
from front panel module to system
board
3 Intrusion switch cable T26139-Y3922-V121 from server front to system board
4
HDD / ODD power
cable
T26139-Y4012-V502
HDD backplanes and accessible
drives to system board
5 ODD SATA cable T26139-Y3928-V205 from optical disk drive to system board
6 SAS / SATA cable T26139-Y3963-V103
from SAS / SATA backplane to system
board or SAS controller
7 System power cable T26139-Y3952-V611
from power distribution board to
system board
8
Power supply unit
signal cable
T26139-Y3956-V2
from power distribution board to
system board
9
If BBU installed:
BBU cable
T26139-Y3987-V2 from BBU to RAID controller
10
If FBU installed:
FBU adapter cable
T26139-Y4032-V3 from FBU to RAID controller
11
PCI riser card power
cable
T26139-Y4029-V202 from PCI riser card to HDD backplane
12
SAS backup drive
power / data cable
T26139-Y3969-V401
from SAS backup drive to HDD
backplane
13 USB 2.0 cable T26139-Y3973-V2
from USB backup drive to system
board
14 USB 3.0 cable T26139-Y4039-V80
from USB backup drive to USB 3.0
interface card
Table 8: List of used cables
