Fujitsu PRIMERGY TX140 S2 - Installing the New Standard Power Supply Unit

104 Upgrade and Maintenance Manual TX140 S2
Power supply
6.2.1.3 Installing the new standard power supply unit
Figure 31: Attaching the installation frame to the power supply unit
Ê Attach the installation frame to the power supply unit.
Figure 32: Securing the installation frame to the power supply unit
Ê Secure the installation frame to the power supply unit with two screws (see
circles).
