318 Upgrade and Maintenance Manual
TX140 S2
Appendix
17.1.3 Server interior
Figure 222: Interior (example: 2.5-inch HDD model, standard power supply)
1 System fan 8 SAS / SATA backplane
2 Expansion card slots 9 HDD / SSD drive bay
3 Processor / heat sink 10 Front panel module bay
4 TPM 11 Accessible drive bay
5 CMOS battery 12 System board D3239
6 UFM 13 Memory modules
7 BBU/FBU 14 Standard power supply unit
