316 Upgrade and Maintenance Manual
TX140 S2
Appendix
3.5-inch HDD model
Figure 219: Server front - 3.5-inch HDD model
1 3.5-inch HDD / dummy module 4 ID card
2 5.25-inch dummy module 5 ODD
3 5.25-inch dummy module 6
Front panel module including front
USB 3.0 connectors
