TX140 S2
Upgrade and Maintenance Manual 321
Appendix
No. Print Description
1 PWR1 ATX power supply connector
2 SATA POWER
Power distribution for SAS / SATA backplanes and
accessible drives
3 PC2009 Power management connector
4 FRONTPANEL Front panel
5 P30 Power supply connector
6 USB FRONT Connector for front USB
7 FAN1 SYS Connector for system fan
8SATA MLC1
SATA MLC connector for 3.5-inch HDD
configurations
9 USB1 AUX (not used)
10 USB1 DAT USB 2.0 connector for accessible backup drive
11 INTR Intrusion switch cable connector
12 UFM Connector for USB Flash Module (UFM)
13 SATA 5 SATA 5 connector
14 SATA 6 SATA 6 connector
15 TPM Connector for Trusted Platform Module (TPM)
16 HDD ACTIVITY (not used)
17 Micro SD
