GE 9100c - Replace the Bag port

9 Repair Procedure
M1207026 9-27
9.12.3 Replace the
Bag port
1. Remove the breathing system.
2. Fully loosen the screw (A) to release the bag port.
3. Pull out the bag port from the manifold.
4. Replace the o-ring as necessary. Lubricate the o-ring sparingly
with Krytox.
5. Replace the bag port in reverse order.
6. Reinstall the breathing system.
7. Perform the checkout procedure (Section 3).
A
O-ring
