1.5 System components
1. Ventilator display
2. Handle
3. Pipeline pressure gauge(s) (upper row)
4. Cylinder pressure gauge(s) (lower row)
5. Vaporizer
6. Paw pressure gauge
7. System switch
8. Caster with brake
9. O
2
flush button
10. ACGO switch (option)
11. ACGO (option)
12. Breathing system
13. Flow controls
14. Mounting arm (option)
Figure 1-1 • Front View
