10 Illustrated Parts
M1207026 10-15
10.11 Flowmeter Module
1
2
2
34
Item Description Stock number Qty
1 Flowhead Module -----------------
ISO -----------------
O
2
N
2
O Air five flowtubes, ISO M1177712-S
O
2
Air four flowtubes, ISO M1177710-S
N
2
O O
2
four flowtubes, ISO M1164286-S
ANSI -----------------
O
2
N
2
O Air five flowtubes, ANSI M1177719-S
O
2
Air four five flowtubes, ANSI M1177717-S
N
2
O O
2
five flowtubes, ANSI M1164287-S
Neutral -----------------
O
2
N
2
O Air five flowtubes, Neutral M1169299-S
O
2
Air four five flowtubes, Neutral M1177725-S
N
2
O O
2
four five flowtubes, Neutral M1169288-S
2 Screw, M4x8 M1168622-S (8)
3 Flowhead panel, for 3 gases M1186905-S
4 Flowhead panel, for 2 gases M1186901-S
