GE 9100c - Display Module

2 Theory of Operation
M1207026 2-17
2.6.1 Display Module The display module includes:
1. Inverter
2. Display Monitor Board (DMB)
3. Speaker
4. LCD display
5. Keyboard front panel
6. Rotary encoder
Figure 2-5 • 9100c Display Module
1
2
3
4
56
