1.3 Supported Input Terminals
This section describes the input terminals supported by this unit.
① Standard 20CH screw terminal
(B-563)
② ② Standard 20CH screwless terminal
(B-563SL)
③ Standard 30CH screwless terminal
(B-563SL-30)
④ Withstand high-voltage high-precision terminal
(B-565)
⑤ 20CH screw terminal for GL840/GLT400
(B-564)
⑥ 20CH screwless terminal for GL840/GLT400
(B-564SL)
The terminal blocks for GL840 and GLT400 (
⑤
to
⑥
) can also be used with the GL860.
