5-4. Station setting
When connecting to the commercially available wireless LAN base unit and controlling multiple GL860s from a PC, the
e-mail send function of the GL860 and Internet connection are available. (The following conditions are required to use
them.)
•
PC connectable to Wireless LAN.
•
Wireless LAN base unit. (Wi-Fi-authenticated devices equipped with wireless LAN base unit functions.)
•
Internet connection environment when connecting to the Internet.
(Internet provider’s contracts and mobile carrier’s contracts, etc.)
•
Internet connection and e-mail send environments when sending the e-mail.
(E-mail and webmail must be able to send and receive in the SMTP and SMTP via the Internet provider.)
Each station function must be set when the GL860 operates as a child unit.
When the station is selected in the wireless LAN settings and the wireless LAN is restarted, the following screen is
displayed.
•
Station (operated as remote unit)
This is the settings for controlling from a PC and transferring data to a PC after connecting to the separately sold wireless
LAN base unit. When in station configuration, wired LAN cannot be used.
•
After executing “Wireless LAN restart” once, the wireless LAN cannot selected. When the wireless LAN selection is
changed, the restart is enabled.
“Disconnect” “Wireless LAN restarting” “TCP-IP restarting” are executed.
<If the NONE> <If the WEP> <If the WPA-PSK/ WPA2-PSK >
Selection item Description
Wireless LAN Switches between Off, Stations and Access points.
Select the setting to change and execute "Wireless LAN Restart".
AUTO SETTING (WPS) Execute auto-connect using WPS. For details, refer to "How to use WPS".
SSID search A list of wireless access points (base unit) can be displayed by searching for an SID.
When you select the access point (base unit) to connect in the list, it is displayed in the SSID input.
SSID input Set the SSID (access point identification name) of the access point (base unit) to be connected.
Up to 32 characters can be entered using alphanumeric characters and symbols.
Encryption method Set the encryption method to NONE, WEP, WPA-PSK/WPA2-PSK.
WEP key Set the WEP key with 10-digit alphanumeric characters for WEP64 and 26-digit alphanumeric
characters for WEP128.
Password Set a password with 8 to 63 alphanumeric characters.
11n Select whether to use wireless standard 11n or not.
Apply settings (Connect) Save the settings and reconnect.
Disconnection Disconnect the wireless LAN connection.
TCP-IP settings Acquire the station IP address setting of the wireless LAN unit automatically or set it manually.
After setting, reflect the settings (" "
key) and restart to complete.
For server settings, refer to "5-9. Network settings".
