Chapter 5 Specification
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
5.2 Function Specifications
Function Specifications
Item Description
Display screen Waveform + Digital screen, All Waveform screen, Digital + Calculation Display screen, Expanded digital
screen, Alarm history screen
* Can be switched using the dedicated key. (toggle operation)
* For the Expanded Digital screen, the number of channels and the display channel must be specified.
* The waveform is not rewritten due to the change of the TIME / DIV.
Sampling interval 5 ms/1 ch maximum (GBD/CSV-formatted)
5, 10, 20, 50, 100, 125, 200, 250, 500 ms; 1, 2, 5, 10, 20, 30 sec.;
1, 2, 5, 10, 20, 30 min.; 1 hour; External
* The settings of 1 sec or below can be used depending on the input settings and the measuring channel.
EU (scaling function) • 4 points can be set for each channel
• The temperature range scaling function is available.
Functions during capture • Confirmation of the captured data (Switchable between 1-screen and 2-screen)
• Saving of data between cursors
• Replacement of the SD memory card
Data save function Capture destination: Internal memory or SD memory card
Captured data: Settings, Screen data, Measurement data, Alarm history data
Capture function Function: OFF, Ring recording, Relay recording
Ring recording Number of recording points: 1000 to 2000000
* When ring capture is ON, the memory space that can be used for capture is one-third of the free space.
Relay recording Relay capacity: 100MB to 2000MB
Relay time: 1 hour 00 minute to 24 hours 00 minutes
The captured data is continuously captured by files separated in the set relay unit without losing data.
Replaying data GBD/CSV-formatted data file (only data captured in this GL860)
Calculation between CHs Calculation type: Four arithmetic operations (+, -, ×, ÷)
Target input: Analog CH1 to CH200
Statistical calculation Statistical calculation type: Average value, maximum value, minimum value, peak value, root mean
square value
Calculation method: Real-time calculation and specified between cursors (during replay)
* Real-time calculation results are displayed on the Digital screen + Calculation Display screen.
Search functions Function: Search the captured data for the required number of points
Search type: Channel Pulse, Logic, Level, Alarm search
Annotation input function Function: A comment can be entered for each channel
Input table characters: Alphanumerics
Number of characters: 31 (The number of characters can be displayed on the screen is up to eight
characters.)
Navigation function Easy capture measurement, easy trigger setting, wireless LAN setting functions
Trigger/Alarm Functions
Item Description
Repeat Trigger Off, On
Trigger types Start: Data capture starts when a trigger is generated.
Stop: Data capture stops when a trigger is generated.
Trigger conditions Start: Off, Level, Alarm, External, Time, Date, Weekly
Stop: Off, Level, Alarm, External, Time, Date, Weekly
Trigger judgment modes Combination: Level OR, Level AND, Edge OR, Edge AND
Analog channel judgment mode: H ( ), L ( ), Window In, Window Out
Logic channel judgment mode: H ( ), L ( )
Pulse channel judgment mode: H ( ), L ( ), Window In, Window Out
Calculation channel judgment mode: H ( ), L ( ), Window In, Window Out
