5-14
Chapter 5 Specification
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
List of Options
Item Model Description
Input/output cable for GL B-513 2 m long (no clip on end of cable)
DC drive cable B-514 2 m long (no clip on end of cable)
Humidity sensor *
1
B-530 3 m long (with power plug)
Standard 20CH screw terminal B-563 20CH standardt erminal
Standard 20CH screwless terminal B-563SL 20CH screwless terminal
Standard 30CH screwless terminal B- 563SL- 30 30CH screwless terminal
Withstand high-voltage high-precision
terminal
B-565 20CH Withstand high-voltage high-precision terminal
Base unit for input terminal B-566 Extension terminal base unit, connection plate, screws
Connection cable for extension
terminal
B-567-05 Connection cable (50 cm)
B-567-20 Connection cable (2 m)
Wireless unit B-568 Wireless LAN
Battery pack B-573 7.2V/2875mAh
Bracket for DIN rail (GL860 main body) B-570 Built to order
Bracket for DIN rail B-540 Built to order
Shunt resistor B-551 Built to order.
250 Ω, Rated power of 1 W, Maximum service voltage of 15.8 V
Input terminal cover B-588 Protective cover
*1: Allowable temperature range: –25 to +80°C
