5-3
Chapter 5 Specification
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
Item Description
Weight
(approximate) *1
Standard
terminal
1010g
Withstand
high-voltage
high-precision
terminal
1035g
Standard
screwless
terminal
1010g
Vibration- tested conditions Equivalent to Equivalent to Automobile parts Type 1 Class A
Buzzer (key, etc.)
*1: AC adapter and battery are not included., but one terminal unit is included.
Memory devices
Item Description
Memory capacity Internal memory: approx. 8GB
*1
SD CARD slot: 1
*1 *2
Memory contents • Setup conditions
• Measured data
• Screen copy
*1 Possible to save up to 2GByte for one file
*2 SDHC compatible, maximum approx, 32GByte memory is available,Compatible with FAT / FAT32 format only.
PC I/F
Item Description
Interface types Ethernet (10BASE-T/100BASE-TX)
USB 2.0
Wireless LAN (Option)
Functions Data transfer to the PC (real-time, Internal memory or SD CARD data)
PC control of the GL860
Ethernet functions
(10BASE-T/100BASE-TX)
Web server functions: Displays the screen image of the GL860 with a browser, and operates
the GL860.
FTP server function: Transfer and delete the captured data in the internal memory or SD CARD.
FTP client function: Back up the captured data to the FTP server.
NTP client function: Time-synchronize the NTP server.
DHCP client function: IP address automatic acquisition.
DHCP server function : IP address automatic distribution. (Wireless LAN/In access point
mode only)
E-mail function: Send and receive the e-mail
Modbus TCP communication: Communication with sequencers via Modbus TCP.
Link function with G-REMOTE: Linkage with Graphtec’s G-REMOTE service.
USB functions USB drive mode: Transfer and delete the captured data in the internal memory or SD
memory card.
Realtime data transfer speed *1 5 ms/1 ch maximum
*1: The transfer speed depends on the number of channels.
Monitor
Item Description
Display 7-inch TFT color LCD (WVGA: 800 × 480 dots)
Displayed languages Japanese, English, French, German, Chinese, Korean, Russian, Spanish
Backlight life 50,000 hrs (until the brightness is reduced to 50%), It varies with the operating environment.
Backlight Screen saver function provided (10, 30 sec., 1, 2, 5, 10, 30, 60 min.)
