5-4
Chapter 5 Specification
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
B-563/B-563SL Specifications
Item Description
Number of input
channels
Standard 20CH
screw terminal
20 channels (Up to 200 channels when using with the expansion terminal base)
* Between GL860 and terminal and between terminals can be directly connected or with an
expansion terminal connection cable (sold separately)
Standard 20CH
screwless
terminal
20 channels (Up to 200 channels when using with the expansion terminal base)
* Between GL860 and terminal and between terminals can be directly connected or with an
expansion terminal connection cable (sold separately)
Input terminal
type
Standard 20CH
screw terminal
M3 screw-type terminals (Rectangular flat washer)
Standard 20CH
screwless
terminal
Screwless terminal
Input method Photo MOS relay scanning system
All channels isolated, balanced input
Scan speed 5 ms/1 ch maximum
Measurement ranges Voltage: 20, 50, 100, 200, 500 mV, 1, 2, 5, 10, 20, 50, 100 V, 1-5 V F.S.
Temperature
Thermocouples: K, J, E, T, R, S, B, N, C (W: WRe5-26)
Temperature range: 100°C, 500°C, 2000°C (In the case of Fahrenheit: 150°F, 750°F, 3000°F)
Humidity: 0 to 100% (voltage 0 to 1 V scaling conversion) fixed
Measurement accuracy
(23°C ±5°C)
• When 30 minutes or more have
elapsed after power was switched on
• Sampling 1 s/10 ch
• Filter ON (10)
• GND connected
Voltage: 0.1% of F.S.
Temperature
• Thermocouple
Thermocouple Measurement Temperature Range (°C) Measurement Accuracy
R/S 0 ≤ TS ≤ 100℃
100 < TS ≤ 300℃
R : 300 < TS ≤ 1600℃
S : 300 < TS ≤ 1760℃
±5.2℃
±3.0℃
± (0.05% of rdg +2.0℃)
± (0.05% of rdg +2.0℃)
B 400 ≤ TS ≤ 600℃
600 < TS ≤ 1820℃
±3.5℃
± (0.05% of rdg +2.0℃)
K -200 ≤ TS ≤ -100℃
-100 < TS ≤ 1370℃
± (0.05% of rdg +2.0℃)
± (0.05% of rdg +1.0℃)
E -200 ≤ TS ≤ -100℃
-100 < TS ≤ 800℃
± (0.05% of rdg +2.0℃)
± (0.05% of rdg +1.0℃)
T -200 ≤ TS ≤ -100℃
-100 < TS ≤ 400℃
± (0.1% of rdg +1.5℃)
± (0.1% of rdg +0.5℃)
J -200 ≤ TS ≤ -100℃
-100 < TS ≤ 100℃
100 < TS ≤ 1100℃
±2.7℃
±1.7℃
± (0.05% of rdg +1.0℃)
N -200 ≤ TS < 0℃
0 ≤ TS ≤ 1300℃
± (0.1% of rdg +2.0℃)
± (0.1% of rdg +1.0℃)
C (W) 0 ≤ TS ≤ 2000℃ ± (0.1% of rdg +1.5℃)
Reference contact compensation accuracy ±0.5℃
* Thermocouple diameters T, K: 0.32 φ, others: 0.65 φ
