3-82
Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
Custom menu
Setting Selections available
Select from list Select the function you want to use from the list.
Select in Wizard Select the function you want to use in a Wizard format.
6-1. Temperature settings
Make settings for functions related to temperature.
Setting Selections available
Room Tempe Internal, External
Temp unit ℃, ℉
Burnout Off, On
6-1-1. Room temperature compensation
Selection item Description
Internal The room temperature compensation in the GL860 is enabled.
(Please usually select the "Internal".)
External This is used to execute the room temperature compensation through an external device.
6-1-2. Temp. Unit
Toggles the temperature unit between °C (Centigrade) and °F (Fahrenheit) for temperature settings.
Selection item Description
℃ Set temperature units to Celsius.
℉ Set temperature units to Fahrenheit.
When °F (Fahrenheit) is selected, a calculation is performed using the following formula:
°F (Fahrenheit) = °C (Centigrade) × 1.8 + 32
Calculate the accuracy as: Centigrade accuracy × 1.8.
6-1-3. Burnout
Sets a feature that checks sensor burnout in a thermocouple.
Selection item Description
Off The burnout check is disabled.
On A periodic burnout check is conducted.
During a burnout check, voltage is applied to the GL860. Therefore, set Burnout to “Off” when GL860 is connected in
parallel with other devices to avoid any effect from these voltages.
CAUTION
