2-26
CHAPTER 2 Checks and Preparation
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
2.11
Connecting to a PC
Use the USB or LAN Interface to connect the GL860 to a PC.
Connection Using a USB Cable
Connect between the GL860 and PC with the USB cable.
USB cable
The USB connector is adjacent to the LAN connector. Make sure the cable is inserted into the correct connector.
CAUTION
If the USB cable is used, the USB driver must be installed in your PC. For the installation procedure, refer to the attached
“USB Driver Installation Manual”.
Use the cable with A and B connectors to connect the GL860 to a PC.
A connector B connector
To Next Page
