2-27
CHAPTER 2 Checks and Preparation
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
LAN Connection
Use a LAN cable to connect the GL860 to a PC.
LAN cable
Cable Types
Use a crossing cable when connecting directly to a PC, without using a hub.
PC GL860
Use a straight cable when using a hub.
PC
GL860GL860
