CHAPTER 2 Checks and Preparation
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
Connection through the wireless LAN (Option)
Insert the wireless LAN unit (B-568: Option).
For the insertion, refer to "2.10 Installing the Wireless LAN Unit (B-568: Option)".
1. Access point (operating as a base unit):
The following devices and operating environments are required to connect the GL860 to a PC or smartphone via
wireless LAN.
•
PC and Smartphone which can connect to the wireless LAN
PC: Child unit
GL860: Base unit
Smartphone: Child unit
Wireless connection
Wireless connection
2. Stations (operating as a child unit):
When connecting to the commercially available wireless LAN base unit and controlling multiple GL860s from a PC,
the following devices and the operating environment are required.
•
PC and Smartphone which can connect to the wireless LAN with the dedicated software
•
Wireless LAN base unit (equipped with the functions of Wi-Fi authenticated wireless LAN base unit.)
•
Internet environment for Internet connection (Internet provider’s contracts and mobile carrier’s contracts)
•
Internet connection and e-mail send/receive environment (Internet provider and Webmail, etc.) when sending/
receiving e-mail.
PC: Child unit
Smartphone: Child unit
親機
GL860: Child unit
GL860: Child unit
Wired LAN connection
Wireless connection
Wireless connection Wireless connection
Wireless connection
