5-2
Chapter 5 Specification
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
5.1
Standard Specifications
Standard Specifications
Item Description
Number of analog inputs Maximum 200ch available for 1 terminal(20ch/30ch) or extension unit
Analog terminal unit type • Standard 20CH screw terminal
• Standard 20CH screwless terminal
• Standard 30CH screwless terminal
• Withstand high-voltage high-precision terminal
Data backup functions Setup parameters: EEPROM/Clock: Lithium battery
Clock accuracy (23°C environment) ±0.002% (accurate within about 50 seconds per month)
Operating environment 0 to 45°C, 5 to 85% RH
(0 to 40°C when operated in batteries/15 to 35°C when a battery is charging)
Withstand
voltage
Standard
terminal
Between each input ch and GND terminal: 350Vp-p 1 minute
Between each input terminal: 350Vp-p 1 minute
Withstand
high-voltage
high-precision
terminal
Between each input ch and GND terminal: 2300VACrms 1 minute
Between each input terminal: 600Vp-p
Power supply • AC adapter: 100 to 240 VAC, 50 to 60 Hz
• DC input: 8.5 to 24 VDC (26.4 V max.)
• Battery pack (option): 7.2 VDC (2875 mAh), two packs can be mounted
Power consumption
AC power consumption (when using the AC adapter provided as a standard accessory)
No. Condition
Power
supply
Normal
During
recharging
battery
1 When the LCD is on AC100V 24VA 38VA
AC240V 35VA 55VA
2 When the screen saver is operating AC100V 19VA 33VA
AC240V 27VA 49VA
DC current consumption
No.
DC
voltage
Condition Normal
During
recharging
battery
1 +24V When the LCD is on 0.36A 0.65A
2 When the screen saver is operating 0.27A 0.56A
3 +12V When the LCD is on 0.70A Recharging
not possible
4 When the screen saver is operating 0.50A Recharging
not possible
5 +8.5V When the LCD is on 1.00A Recharging
not possible
6 When the screen saver is operating 0.70A Recharging
not possible
* Normal condition: LCD brightness is set to MAX.
External
dimensions
(approximate)
[W × D × H ]
Standard
terminal
240 × 158 × 52.5mm (not including protruding parts)
Withstand
high-voltage
high-precision
terminal
240 × 166 × 52.5mm (not including protruding parts)
Standard
screwless
terminal
240 × 158 × 52.5mm (not including protruding parts)
To Next Page
