Chapter 2 Checks and Preparation
This chapter explains how to check the main module's external casing and accessories, and how to prepare the main
module for operation.
SECTION IN THIS CHAPTER
2.1 Checking the Outer Casing
2.2 Checking the Accessories
2.3 Mounting and removing each terminal
2.4 Mounting the Extension Terminal Base (Optional) and Extension Terminal Cable (Optional)
2.5 Nomenclature and Functions
2.6 Connecting the Power Cable and Turning on the Power
2.7 Connecting the Signal Input Cables
2.8 Logic Alarm Cable Connection and Functions
2.9 Mounting the SD Memory Card
2.10 Installing the Wireless LAN Unit (B-568: Option)
2.11 Connecting to a PC
2.12 Using the Battery Pack (B-573/B-569: Option)
2.13 Connecting the Humidity Sensor
2.14 Precautions to Observe When Performing Measurement
2.15 Noise Countermeasures
2.16 When Fixing the GL860 Main Unit
2.17 Setting the Date and Time
