5-12
Chapter 5 Specification
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
5.3 Accessories/Optional Accessories
Control Software
Item Description
Compatible operating system Windows 11 / Windows 10
Function Main unit control, real-time data capture, data conversion
Number of groups 4 groups MAX
Number of CHs per 1 group Up to the number of connected modules
Maximum number of channels 1000 ch maximum
Settings AMP settings, capture settings, trigger/alarm settings, report settings, others
Captured data Realtime data (CSV, GBD Binary)
Data in Internal memory or SD memory card (CSV, GBD binary)
Display Analog waveforms, logic waveforms, pulse waveforms, digital values
Display modes Y-T View, Digital View, Report View, X-Y View between Cursors (only during replay),
Integrated bar graph display
File conversion Between cursors, All data
Monitor functions The alarm monitor enables the sending of emails to the specified address
Statistic/History Displays maximum, minimum and average values during measurement
Report function Enables the creation of daily or monthly files
E-mail function The e-mail is sent to the specified address when the alarm monitor is performed.
Accessories
Item Description
Quick Start Guide GL860-UM-80x: 1
AC adapter 100 to 240 VAC, 50/60 Hz, Power supply cord for each area: 1
Wireless Unit B-568 (Option)
Item Description
Communication system Wireless LAN
Installation Attach to the wireless LAN connection terminal
* When the wireless unit is inserted, the SD memory card cannot be inserted into the SD
CARD slot.
Wireless LAN standard IEEE802.11b/g/n
Function Control from PC, data transfer to PC, control and data transfer from smartphone/tablet
For access point: Local control and transfer are possible.
For station: In addition to local, remote control and transfer using G-REMOTE is also
possible.
Communication range: Approx. 40 m
* Communication range depends on the obstacles and the surrounding environmental
conditions.
WPS: Push button method / PIN method
Encryption function: WEP64, WEP128, WPA-PSK/WPA 2-PSK (TKIP/AES)
* WPA/WPA2 and TKIP/AES are automatically selected.
