5-18
Chapter 5 Specification
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
GL860 Withstand high-voltage high-precision terminal (B-565))
11
218
2-M4 L5 ②②②
Unit: mm
Dimension precision: 3 mm
Terminals
2.5
12
6.2
7.624.5
Unit: mm
Dimension precision: ± 0.5 mm
