GEN7iB
110
SETTING UP THE GEN7iB
SETTING UP THE GEN7iB
7
7.9 Airlterreplacement
HBM uses state-of-the-art electronic components in its equipment. These electronic
components can be damaged by discharge of static electricity (ESD). ESD damage is quite
easy to induce, often hard to detect, and always costly. Therefore, we must emphasize
the importance of ESD preventions when handling a GEN7iB system, its connections or a
plug-in card.
Toreplacetheairlter:
1. Power off the GEN7iB system and remove the power input cable.
2. Disconnect all cables from the acquisition cards.
3. Removethescrewsfromtheairlterlockingbracket.
Fig. 7.27 Unlock screws on the air îž’lter access panel
