HBK GEN7iB GEN Series User Manual

GEN7iB
332
UNDERSTANDING INPUTS AND USAGE OF PROBES
UNDERSTANDING INPUTS AND USAGE OF PROBES
15
15.1.1 Single-ended input
A single-ended input is not isolated and uses unbalanced inputs
*1'
8
LQ

N
N

±
Fig. 15.1 Single-ended amplier
● One input is connected to ground
● Resistance / Capacitance from each terminal to ground is different
● Amplieristypicallyfoundinoscilloscopes
● Also used in GEN DAQ Basic amp, Liberty 8ch DC amp
● OftenidentiedbytheuseofasingleMETALBNCconnectorperchannel
● Can be used with standard passive probes (as with oscilloscopes)
