GEN series SYNCHRONIZATION METHODS
GEN series SYNCHRONIZATION METHODS
14
14.3.3 Setup comparison
GPS and G002B setup
Synchronization
characteristic
G002B directly to
mainframe
G002B with Master/
Sync connected
mainframes
G002B with Teth-
ered mainframes
Accuracy 150 ns to UTC 150 ns to UTC 150 ns to UTC
Geographical distri-
bution
Worldwide Limited to the
Master/Sync range
Limited to the PTP
network range
Scalability Unlimited Up to 128 mainframes Depends on the
PTP network
setup.
No QuantumX Supports QuantumX
Note
Can be combined
with Master/Sync to
extend scalability
Complexity Low Medium High
Requires Master/
Sync setup
Requires correct setup
of PTP network
Electrical safety Highest High Depends on PTP
network
Built-in Surge Protec-
tor
(1)
anduseofber
optical connection.
Built-in Surge Protec-
tor
(1)
anduseofber
optical connection.
No link between main-
frames
Cost High Low Medium
Each mainframe re-
quires a PTP master
One Master Output
card needed for every
four Sync mainframes
PTP network setup
Reliability High Medium Unknown
No SPOF (Single Point
of Failure)
2 x SPOF 1x known SPOF
G002B antenna G002B antenna +
Master mainframe PTP aware network
(1)
Note
Surge Protector grounding must be lightning safe.
