GEN7iB

150

INTERFACE/CONTROLLER

11.3.2 Connecting multiple mainframes using the Master/Sync card

ThemultiplemainframeMaster/Syncsetuponlyworksinastarconguration.AllMas-

ter/SyncberopticcablesareononesideconnectedtotheMastermainframewhile

the other side connects to one Sync mainframe.

The master mainframe needs to be extended with one or more optional option carrier

cards (G081). Each option carrier card can be extended with one or two Master output

cards (G083).

Maximum Master/Sync overview Maximum Master/Sync overview

Option Carrier Card Master Output Card Sync Mainframes

GEN2tB 1 2 9

GEN3i 2 4 17

GEN3iA 2 4 17

GEN4tB 3 6 25

GEN7i/GEN7iA/

GEN7iB

6 12 49

GEN7tA/GEN7tB 6 12 49

GEN17tA/GEN17tB 16 32 129
