GEN7iB
477
PTP SYNCHRONIZATION
PTP SYNCHRONIZATIONG
G.3 Synchronizing GEN series and QuantumX using PTP
G.3.1 GEN3i with single QuantumX "B" version module
Fig. G.10 GEN3i with single MX1609KB/MX1609TB - Overview
Setup only shows GEN3i. GEN3i can be replaced by GEN3iA/GEN7i/GEN7iA/GEN7iB.
Setup only shows MX1609KB, MX471B (CAN) could also be used.
With Perception SW version 7.40 the QuantumX support will be stopped. In future versions of
Perception, the QuantumX modules can then be integrated via CAN at tethered mainframes.
