GEN7iB
297
GEN series SYNCHRONIZATION METHODS
GEN series SYNCHRONIZATION METHODS
14
14.3 GPS
14.3.1 Installation
When connecting the GPS antenna to the mainframe, please follow the steps
described below.
Impor
As the GPS antenna is typically placed on a roof or otherwise hard to access position, it is
highly recommended to connect the GPS antenna to the PoE injector and plug the injector
into mains. Please refer to the LED overview to verify that the GPS antenna is properly pow-
ered and optionally connect to the web client to verify the GPS antenna is fully operational.
1. Place the GPS antenna in a position with clear view to the sky. For more informa-
tion, please refer to chapter „GPS antenna placement“ on page 316.
1A Test: Power the antenna temporarily and verify if satellites can be found using
the antenna’s web interface.
For this test, the antenna should be connected directly to a PC, not the GEN series main-
frame.
2. Create outdoor/indoor pass through, ensure enough space is available to position
the Surge Protector.
Make sure the wall pass through is clean and does not contain sharp edges or objects that
may damage the cable.
3. Place the Optical Ethernet power over Ethernet Injector (PoE) and connect to
mains power.
Verify that the power LED is lit.
4. Make sure the section of cable between the Surge Protector and PoE injector that
is outside of the wall is as short as possible.
Make sure the îž’ber optic cables do not break or get damaged when connecting.
To Next Page
