GEN7iB
23
SAFETY MESSAGES
SAFETY MESSAGES
2
Usingthetableabove,itcanbeconcludedthatthisspecicationinformstheuserthat
the device passed the insulation tests; 5 sec at 2210 V RMS and impulse 4000 V. The
maximum operating input voltage is 1000 V DC. This device is to be used to measure
CAT II circuitry up to 600 V.
Measurement inputs of this instrument should not be used to measure high-energy signals
of measurement categories CAT II, CAT III or CAT IV (IEC 61010-2-030:2017) (e.g. mains
measurements) , unless speciîž’cally stated for the speciîž’c input.
2.4.2 Basic insulation versus reinforced
For reference, the basic insulation and supplementary insulation and the reinforced
insulation test values for CAT II can be found below.
Nominal voltage
line to neutral AC
RMS or DC of
MAINS being mea-
sured. [V]
Test voltage
5 s AC test [V RMS] Impulse test [V peak]
Basic insu-
lation and
supplementary
insulation
Reinforced
insulation
Basic insu-
lation and
supplementary
insulation
Reinforced
insulation
≤150 840 1390 1550 2500
>150≤300 1390 2210 2500 4000
>300≤600 2210 3510 4000 6400
>600≤1000 3310 5400 6000 9600
Tab. 2.2 Test voltages for the testing electric strength of solid insulation in measuring
circuits in measurement category II (IEC 61010-2-030:2010)
Several means of protection can be used to protect a user from hazardous voltages.
As can be seen below, basic insulation and supplementary insulation is one mean of
protection, but reinforced insulation is also a means of protection.
The test voltages are different for each mean of protection, as can be found in the table
above.
