GEN series SYNCHRONIZATION METHODS
GEN series SYNCHRONIZATION METHODS
14
14.4.3 Using the GMR1000 module
The GMR1000 unit takes the IRIG signal as time source input and acts as a PTP mas-
ter clock for the rest of the system (see Figure Fig. 14.38).
*05
373 173
0DVWHUFORFN

/2&.
,5,*6RXUFH
(WKHUQHW
373*UDQGPDVWHU
&ORFN
Fig. 14.38 G001B architecture
Notice
This means that most references in the system setup are PTP related, and not IRIG related.
