HBK GEN7iB GEN Series User Manual

GEN7tB
68
INTRODUCTION
INTRODUCTION
6
6.2.1 Mainframe feature comparison
GEN DAQ Features (1)
Mainframe Standard streaming (cPCI backplane) Fast Streaming (PCI-e backplane) Option carrier card EtherCAT
®
support
1-GEN3i, 1-GEN3iA, 1-GEN7i and
1-GEN7iA/B
Yes Yes Yes No
1-GEN2tB No Yes Yes No
1-GEN4tB No Yes Yes Yes
1-GEN7tA and 1-GEN17tA Yes Yes Yes Yes
1-GEN7tB and 1-GEN17tB Slots A, B, C
only
Yes Yes Yes
GEN DAQ Features (2)
IRIG/GPS and Ethernet PTP synchronization IRIG and IRIG/GPS synchronization 1 Gbit Ethernet (RJ45, electrical) PTP synchronization 1 Gbit Ethernet (SFP, optical) PTP synchronization 10 Gbit Ethernet (RJ45, electrical) without PTP synchronization 10 Gbit Ethernet (SFP, optical) without PTP synchronization
1-GEN3i, 1-GEN3iA, 1-GEN7i,
1-GEN7iA/B, 1-GEN2tB, 1-GEN4tB,
1-GEN7tA/B and 1-GEN17tA/B
Yes Yes Yes No No
