GEN7iB
209
INPUT CARDS
INPUT CARDS
12
12.3 Isolated 1kV input cards
12.3.1 GN610B, Isolated 1kV 2MS/s input card with real-time formula database
● 6 analog channels
● Isolated, balanced differential inputs
● ± 10 mV to ± 1000 V input range
● Basic accuracy 0.02%
● Basic power accuracy 0.02%
● 600 V RMS CAT II reinforced insulation, tested up to 6.4 kV
● Analog/digitalanti-aliaslters
● 18 bit at 2 MS/s sample rate
● Real-time formula database calculators
● Triggering on real-time results
● Digital Event/Timer/Counter support
● 1 kV RMS CAT IV probe
● 5kVRMScertiedprobe
The isolated balanced differential input offers voltage ranges from ± 10 mV
to ± 1000 V.
Tested up to 6.4 kV, the reinforced insulation allows for safe measurements
up to 600 V RMS CAT II (without probes).
Anti-alias protection is achieved by a unique, multi stage approach. The
rststagecombinesa7-poleanaloganti-aliaslterwiththeAnalog-to-Dig-
ital converter to create an alias free digital data stream at constant rate of
2 MS/s (200 kS/s).
The four Timer/Counters and the G070A torque/RPM adapter allow for
direct interfacing to HBM torque transducers or other torque and speed
sensors.
0N9'&
&$7,,9
0N9'&
&$7,,9
0N9'&
&$7,,9
0N9'&
&$7,,9
0N9'&
&$7,,9
0N9'&
&$7,,9
)$
$
7
The real-time formula database calculators offer math routines to solve almost any
real-time mathematical challenge. Dynamic digital cycle detection enables real-time
storageaswellas1μslatencydigitaloutputofcalculationresultslikeTrue-RMSon
all analog, torque, angle, speed and Timer/Counter channels. Channel to channel math
createscomputedchannelswith1μslatencyobtainingmechanicalpowerand/or
multiphase(notlimitedtothree)electricpower(P,Q,S)oreveneciencycalculations.
Real-time calculated results can be used to trigger the recording or signal alarms to the
external world.
Forspecicationandorderinginformation,pleaserefertotheGN610Bdatasheet.
