GEN7iB

181

INPUT CARDS

Optical Fiber Transmitter Channels

Transmitter

Every transmitter is a single channel unit. Every unit has an unbalanced differential input, ampli-

er,analoganti-aliaslterandADCwithanopticaldataandcontrollinktothereceivercard.The

receiver card has the recording logic, sample rate selection and memory.

Model Receiver card Power Sample rate Resolution Isolation

GN110 GN1202B Battery 100 MS/s 14 bit User applica-

tiondened

GN111 GN1202B Battery 25 MS/s 15 bit User applica-

tiondened

GN112 GN1202B 120/240 V AC 100 MS/s 14 bit 1800 V RMS

GN113 GN1202B 120/240 V AC 25 MS/s 15 bit 1800 V RMS
