GEN7iB
196
INPUT CARDS
INPUT CARDS
12
Reinforced insulation test voltages in accordance with IEC 61010-2-030:2017
Nominal voltage line-to-neutral
AC RMS or DC of
MAINS
being
measured
IEC 61010-2-030:2017 Reinforced insulation
5 sec. AC test [V RMS]
CAT II CAT III CAT IV
≤150
2.700 2.210 3.510
>150≤300
3.000 3.510 5.400
>300≤600
3.510 5.400 7.400
>600≤1000
5.400 7.400 11.940
Using the tables “Basic/Reinforced insulation test voltages in accordance with IEC
61010-2-030:2017”,itcanbeconcludedthatthisspecicationinformstheuserthat
a high voltage input within the device has passed the insulation test; 5 sec at 6600 V
RMS for the rating of 1000 V CAT IV basic insulation.
For a voltage channel, input to chassis has passed the isolation tests of 5 sec at
7400 V RMS for the rating of 1000 V CAT III reinforced insulation. Tested up to 7400 V
RMS for 5 s, the reinforced and double insulation allows for safe measurements up to
1000 V CAT III (without probes) from voltage channel to chassis.
