GEN7iB
341
UNDERSTANDING INPUTS AND USAGE OF PROBES
UNDERSTANDING INPUTS AND USAGE OF PROBES15
Voltage probes overview table
Part num-
ber
Capacitive
compensa-
tion range
Cable
length
Divider
factor
Bandwidth Maximum
input voltage
1-G901
10 - 25 pF
1.2 m 10 ± 2% 400 MHz 300 V RMS CAT II
1-G903 10 - 50 pF 2 m 100 ± 2% 400 MHz 1 kV RMS CAT II
Passive, single-ended voltage probe overview
Input card 1-G901 1-G903
GN110/GN111
GN112/GN113
GN310B/GN311B
GN610B/GN611B
GN815/GN816
GN840B/GN1640B
GN8101B/GN8102B/GN8103B
GN3210/GN3211
GENIS-1T/GENIS-1TM
