GEN7iB
449
TROUBLE-SHOOTING
TROUBLE-SHOOTINGD
Verify the GEN series network port
The following section explains how the LEDs on the ports can be used to diagnose
system synchronization problems. The images herein are schematic, for actual port
images and positioning of the ports in the system, refer to appendix „PTP Synchroniza-
tion“ on page 468.
PTP1 RJ45 network connection
373
$
%
A Activity LED RJ 45 network (blinking)
B Link speed RJ45 network
