91
────────────────────────────────────────────────────
8.3.3 Specific Commands for Output Settings
────────────────────────────────────────────────────
Syntax
:OSET:FILTer? <ch>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
Example
Transmission
Response
:OSET:FILT? 1
(Header ON)
:OSET:FILTER 1,F100KHZ
(Header OFF)
1,F100KHZ
Syntax
:OSET:FREQuency <ch>,<freq>
<ch> Channel number
= 1 to 4 (1 to 2 for the 7075-01)
<freq>
(Frequency of SIN and rectangular
waveforms)
= 0 to 10000000 [Hz]
(Clock frequency of arbitrary
waveform)
= 0 to 10000000 [Hz]
(Frequency of other waveforms)
= 0 to 200000 [Hz]
Example
Transmission
:OSET:FREQ 1,100000
Sets the frequency for channel 1 to
100 kHz.
Function
Returns the filter for the specified
channel as a character data.
Note
With this query, if any error occurs, no
response message is produced.
Error
(Execution error)
When the specified waveform is a sine
or square wave, or DC
Function
Sets the frequency of a basic
waveform, or the clock frequency of a
arbitrary waveform.
Errors
(Execution error)
When the specified value cannot be
set
When DC or noize is selected as the
waveform type
When sweep is on
:OSET:FILTer?
Queries the filter.
:OSET:FREQuency
Sets the frequency.
