121
────────────────────────────────────────────────────
8.4.2 Specific Commands
────────────────────────────────────────────────────
:OSET
Switches to Output Setting Screen
Commands
Parameters <ch>=channel no.
Explanation
Transmission Response Parameter explanation
:OSET:AWG:LIST?
"<wave1>",
"<wave2>",...
<waveN>= Readable
waveform name list
(character)
Query
:OSET:CLEar
Deletes all waveform.
:OUT
<ch>,ON/OFF
Sets the output.
:OUT?
<ch> <ch>,ON/OFF
Query
:RUN
Start the output.
:RUN?
0/1
0 (during stop)
1 (during output)
Query
:STOP
Stops the output.
:TRIG
Trigger
Waveform input
:LOAD
Commands
Parameters
Explanation
Transmission Response Parameter explanation
:LOAD:LOAD "<file>",<model>,<ch>,
"<file>"= File name
<model>=0 to 11 (NRf)
<word>= number of
words to load (NRf)
<atn>= attenuation
A1/A0_1/A0_01/AUTO
Reads the waveform file.
(Information of the
waveform file)
:LOAD:LOAD? "<file>" "<file>",<model>,
"<ch>", <word>
"<ch>"=0(none)/
1(present)
Query
:LOAD:SWEep "<file>",<ch>
Reads the sweep file.
To Next Page
