Hitachi WJ200 Series

3−85
Input Function Summary Table – This table shows all thirty-one intelligent input
functions at a glance. Detailed description of these functions, related parameters and
settings, and example wiring diagrams are in “Using Intelligent Input Terminals” on
page 4-8.
Input Function Summary Table
Option
Code
Terminal
Symbol
Function Name Description
00
FW FORWARD Run/Stop
ON Inverter is in Run Mode, motor runs forward
OFF Inverter is in Stop Mode, motor stops
01
RV Reverse Run/Stop
ON Inverter is in Run Mode, motor runs reverse
OFF Inverter is in Stop Mode, motor stops
02
CF1 *1
Multi-speed Select,
Bit 0 (LSB)
ON Binary encoded speed select, Bit 0, logical 1
OFF Binary encoded speed select, Bit 0, logical 0
03
CF2
Multi-speed Select,
Bit 1
ON Binary encoded speed select, Bit 1, logical 1
OFF Binary encoded speed select, Bit 1, logical 0
04
CF3
Multi-speed Select,
Bit 2
ON Binary encoded speed select, Bit 2, logical 1
OFF Binary encoded speed select, Bit 2, logical 0
05
CF4
Multi-speed Select,
Bit 3 (MSB)
ON Binary encoded speed select, Bit 3, logical 1
OFF Binary encoded speed select, Bit 3, logical 0
06
JG Jogging
ON
Inverter is in Run Mode, output to motor runs at jog
parameter frequency
OFF Inverter is in Stop Mode
07
DB External DC braking
ON DC braking will be applied during deceleration
OFF DC braking will not be applied
08
SET
Set (select) 2nd Motor
Data
ON
The inverter uses 2nd motor parameters for
generating frequency output to motor
OFF
The inverter uses 1st (main) motor parameters for
generating frequency output to motor
09
2CH
2-stage Acceleration
and Deceleration
ON
Frequency output uses 2nd-stage acceleration and
deceleration values
OFF
Frequency output uses standard acceleration and
deceleration values
11
FRS Free-run Stop
ON
Causes output to turn OFF, allowing motor to free
run (coast) to stop
OFF
Output operates normally, so controlled
deceleration stop motor
12
EXT External Trip
ON
When assigned input transitions OFF to ON,
inverter latches trip event and displays
E 12
OFF
No trip event for ON to OFF, any recorded trip
events remain in history until reset
13
USP
Unattended Start
Protection
ON
On powerup, the inverter will not resume a Run
command (mostly used in the US)
OFF
On powerup, the inverter will resume a Run
command that was active before power loss
14
CS
Commercial power
source switchover
ON Motor can be driven by commercial power
OFF Motor is driven via the inverter
15
SFT Software Lock
ON
The keypad and remote programming devices are
prevented from changing parameters
OFF The parameters may be edited and stored
16
AT
Analog Input
Voltage/Current Select
ON
Refer to “Analog Input Settings” on page 3-13.
OFF
18
RS Reset Inverter
ON
The trip condition is reset, the motor output is
turned OFF, and powerup reset is asserted
OFF Normal power-ON operation
19
PTC
PTC thermistor Thermal
Protection
(C005 only)
ANLG
When a thermistor is connected to terminal [5] and
[L], the inverter checks for over-temperature and
will cause trip event and turn OFF output to motor
OPEN
A disconnect of the thermistor causes a trip event,
and the inverter turns OFF the motor
