Honeywell Farenhyt IFP-2000 User Manual

151430-L8 Before You Begin Installation
3-2
X *I/O 2 Flexput™ Circuits 24 VDC 3.0A notification and auxiliary
power circuits
0
O 100 mA for initiation circuits
X *I/O 3 Flexput™ Circuits 24 VDC 3.0A notification and auxiliary
power circuits
0
O 100 mA for initiation circuits
X *I/O 4 Flexput™ Circuits 24 VDC 3.0A notification and auxiliary
power circuits
0
O 100 mA for initiation circuits
X *I/O 5 Flexput™ Circuits 24 VDC 3.0A notification and auxiliary
power circuits
0
O 100 mA for initiation circuits
X *I/O 6 Flexput™ Circuits 24 VDC 3.0A notification and auxiliary
power circuits
0
O 100 mA for initiation circuits
X *I/O 7 Flexput™ Circuits 24 VDC 3.0A notification and auxiliary
power circuits
0
O 100 mA for initiation circuits
X *I/O 8 Flexput™ Circuits 24 VDC 3.0A notification and auxiliary
power circuits
0
O 100 mA for initiation circuits
B SBUS1 OUT SBUS communication 5 VDC 100 mA 0
A
+ SBUS power 24 VDC 1.0 A
-
B SBUS1 IN Used for Class A installations 0
A
+
-
B SBUS2 OUT SBUS communication 5 VDC 100 mA 0
A
+ SBUS power 24 VDC 1.0 A
-
B SBUS2 IN Used for Class A installations 0
A
+
-
A NETWORK NETWORKING
CONNECTION
5V 100mA N/A
B
GND
N.C. RELAY 1 General Purpose Relay 1 24 VDC 2.5 A, resistive N/A
C
N.O.
Terminal Label Description Rating
Earth Ground
Faults
Voltage Current
* Regulated for NAC circuits, special application when used for releasing or auxiliary power circuits.
