Model IFP-2000/ECS Installation Manual 151430-L8
3-3
N.C. RELAY 2 General Purpose Relay 2 24 VDC 2.5 A, resistive N/A
C
N.O.
N.C. TROUBLE Trouble Relay 24 VDC 2.5 A, resistive N/A
C
N.O.
S- SLC OUT SLC terminals 32 VDC 150 mA 0
S+
SC- SLC IN Used for Class A installations 0
SC+
Ring Phone Line 1 Telco Ring N/A 0
Tip Phone Line 1 Telco Tip
Ring Phone Line 1 Premises Ring
Tip Phone Line 1 Premises Tip
Ring Phone Line 2 Telco Ring N/A 0
Tip Phone Line 2 Telco Tip
Ring Phone Line 2 Premises Ring
Tip Phone Line 2 Premises Tip
+ Battery Battery Connection 24 VDC 1.12 A N/A
–
Terminal Label Description Rating
Earth Ground
Faults
Voltage Current
