151430-L8 Before You Begin Installation
3-18
Program type of switch (manual pull, fire drill, and so on), if necessary. (JumpStart
AutoProgramming assigns all switches as Manual Pull type.)
9.5
If the installation includes duct detectors, program detector type. (JumpStart
AutoProgramming does not distinguish duct detectors from ordinary smoke
detectors.)
9.5
Assign input points to zones, if necessary. (JumpStart AutoProgramming assigns all
input points to Zone 1.)
9.5
Zone Configuration
Select alarm delay options (detection characteristics) for zone.
9.3.1.2
Select heat detector trip temperature and/or smoke sensitivity level for photoelectric
smoke detectors.
9.3.1.2
Output Point Configuration
Conventional notification circuits (circuits 1-8):
Enable circuits used for notification appliances through programming, (if necessary).
9.5
Conventional relay circuits (circuits 9-10):
Select options for relay circuits, if desired. Note: Relay circuits will always output
continuously (constant pattern), even if assigned to an Output Group that uses a
different output pattern.
9.5
Auxiliary power circuits (circuits 1-8):
Enable any circuit used for auxiliary power devices through programming.
9.5
Select type of power (door holder, constant, or resettable)
9.5
Addressable relay modules
Assign addressable relay modules to output groups through programming.
(JumpStart AutoProgramming assigns all relay modules to Group 1.)
9.5
LED output points (from the 5880 LED I/O module or 5865 LED Annunciator)
Assign LED modules to output groups through programming.
9.5.3
All output circuits (1-8):
Disable (set to UNUSED) any unused circuits. If you do not disable unused output
circuits, they will cause a trouble condition (unless an EOL resistor is used).
9.5
Select a name for the point.
9.5.2
Output Group Configuration
Add a group to the system if it does not already exist.
9.4.2
Assign output points to a group.
9.5
Assign a name (or description) for a group.
9.4.1.1
Select “group properties” (see below).
Select options for activation with system switches.
9.4.1.2
Emergency Communication System
Edit Lockout and Relinquish Timers.
6.5.1
Edit Auto Reset for ECS events.
6.5.1.2
Edit Voice Commands for events.
6.5.2
Edit VCM/RVM properties, including name, switch expanders, associating keypads,
and priorities. Creating an LOC.
11.2
Task
See Section
(for more info.)
