HP 1660 Series User Manual

Acquire the data
11 Press the RUN key. The clicking of attenuator relays should be audible. Verify
resistance readings on the digital multimeter of 50 Ω ± 0.5 Ω (49.5 to 50.5 Ω).
Record the reading in the performance test record.
22 In the Channel menu change the Coupling field to 1MΩ / DC. The clicking of
attenuator relays should be audible.
33 Press the RUN key. Verify resistance readings on the digital multimeter of 1 MΩ ±
10 kΩ (0.990 to 1.010 MΩ). Record the reading in the performance test record.
44 In the Channel menu change the Coupling field to 50 Ω/DC and V/Div to 200 mV/Div.
Repeat steps 1 through 3.
55 In the Channel menu change the Coupling field to 50 Ω /DC and V/Div to 1 V/Div.
Repeat steps 1 through 3.
66 In the Channel menu change the Coupling field to 50 Ω /DC and V/Div to 4 V/Div.
Repeat steps 1 through 3.
77 Connect the male end of the BNC tee to the channel 2 input of the oscilloscope
module.
88 Repeat from "Set up the logic analyzer" for channel 2, replacing channel 1 with
channel 2 where applicable.
See Also If a reading is not within limits, then the attenuator for the out-of-bounds channel should be
replaced ( see chapter 6) .
Perform an operational accuracy calibration
At this point, an operational accuracy calibration should be performed. Follow the
procedure in chapter 4, "To calibrate the oscilloscope."
Perform an operational accuracy calibration
3–71

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
