HP 1660 Series User Manual

Specifications (logic analyzer)
The specifications are the performance standards against which the product is tested.
Maximum State Speed 100 MHz
Minimum St ate Clock Pulse Width
*
3.5 ns
Minimum Master to Master Clock Time
*
10.0 ns
Minimum Glitch Width* 3.5 ns
Threshold Accuracy ± ( 100 mV + 3% of
threshold setting)
Setup/Hold Time:
*
Single Clock, Single Edge 0.0/3.5 ns through 3.5/0.0 ns,
adjustable in 500-ps increments
Single Clock, Multiple Edges 0.0/4.0 ns through 4.0/0.0 ns,
adjustable in 500-ps increments
Multiple Clocks, Multiple Edges 0.0/4.5 ns through 4.5/0.0 ns,
adjustable in 500-ps increments
*
Specified for an input signal VH = − 0.9 V, VL = − 1.7 V, slew rate = 1 V/ns, and threshold = − 1.3 V.
General Information
Specifications (logic analyzer)
1–3

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
